Single Lumen Extension Set with Check Valve with Negative Needlefree Valve

Product Code: ODEL050-1LCV-NG

It is a closed, needle-free extension set that provides safe and effective IV access for the infusion of IV fluids, medications and blood. It can be used safely in most clinical applications and patient care areas. The pump can be connected to peripheral IV catheters and other central catheters to deliver gravity or bolus infusions. Variants with check valve eliminate the risk of reflux and therefore the risk of over-medication.

Features:

– Smooth, swabable needlefree connector
– Septum forming tight seal to protect against contamination
– Straight fluid pathway to make flushing more effective
– Split Septum
– Transparent housing to encourage complete and effective flushing
– DEHP free, Latex free
– Sterile & Single Use

ODEL050-1LCV-NGSINGLE LUMEN EXTESION SET WITH CHECKVALVE WITH NEGATIVE NEEDLEFREE VALVE
GTIN8680836100949
Compatibility* Compatible with all types of luer devices including all glass syringes
* Connects securely with all standard luerslip and luerlock syringes and connectors - MRI/CT compatible - Pre-Filled Glass Syringe compatible
* Lipid & Blood
* Alcohol Resistant
* Cytotoxic Drug
Priming Volume0,56 ml
Gravity Flow Rate126 ml/min
Pressure Ressitance45 psi
Flow Rate per Lumen126 ml/min
Priming Volume per Lumen0,56 ml
SterilizationEthilen Oxide
Shelf Life5-year
Weight5,40 gr
Dimension13,5 cm
Box150 pcs
Product Components* 1 Negative Needlefree Connector
* 1 Tube 7cm (ID 1.3 x OD 2.3)
* 1 Female Connector
* 1 Valve Cap
* 1 Check valve
* 1-Clamp
* 1 RMLL and RMLL Cap
